drylin® E Linear modules with lead screw

drylin linear axes with spindles are suitable for a wide range of adjustment tasks. They are a popular choice when it comes to ensuring precise positioning. In our online store for spindle axes, you will find a wide variety of product designs. Buy linear modules of various sizes with trapezoidal or steep thread spindles here. We offer spindle linear units that can be set in motion both manually (e.g. with a handwheel) and electrically with an electric motor. Selected models in standard lengths are available from stock.

Number of products: 36

New

drylin® SLN-0232 econ linear module

  • Entry-level model with basic slide made of igus® polymer
  • For the smallest installation spaces
  • Stroke length 40 mm
  • Pitch 6.35 x 25.4 mm
  • Handwheel included, ⌀ 22 mm
Upon request
1 items, thereof ready for shipping:
1 in 48 hours
To the product page

drylin® SAW-1080 linear module with stepper motor

  • With trapezoidal thread TR12x3
  • NEMA24 stepper motor
  • Carriage length: 100mm
  • Stroke length: 500mm
Configure individual linear module!
  • Thread type: Trapezoidal threads
982.46 USD/Pc.
1 items, thereof ready for shipping:
1 in 24 hours
To the product page

drylin® SLW-1040 linear module

  • With trapeziodal lead screw TR10x2
  • Lead screws with ball bearings
  • Carriage length: 100mm
  • Stroke lengths in 250 and 500 mm
Configure individual linear module!
  • Thread type: Trapezoidal threads
318.72 USD/Pc.
2 items, thereof ready for shipping:
2 in 4 weeks
To the product page

drylin® SLW-1040 linear module manual accessories

  • With trapeziodal lead screw TR10x2
  • With manual clamp and position indicator
  • Ball bearing lead screw support
  • Carriage length: 100mm
Configure individual linear module!
  • Thread type: Trapezoidal threads
416.64 USD/Pc.
2 items, thereof ready for shipping:
2 in 4 weeks
To the product page

drylin® SAW-0660 linear module with high helix thread

  • Stainless steel high helix thread and machined end
  • Hard anodised aluminium profile (angular)
  • Carriage length: 100mm
  • Stroke lengths: 100mm or 500mm
Configure individual linear module!
  • Thread type: High helix threads
403.70 USD/Pc.
2 items, thereof ready for shipping:
2 in 4 weeks
To the product page

drylin® SAW-1080 linear module with high helix thread

  • With high helix thread and machined end
  • Hard anodised aluminium profile (angular)
  • Carriage length: 100mm
  • Stroke lengths: 250 mm or 500mm
Configure individual linear module!
  • Thread type: High helix threads
523.62 USD/Pc.
2 items, thereof ready for shipping:
1 in 24 hours
To the product page

drylin® SHT-12 linear module with trapezoidal thread

  • Trapeziodal lead screw
  • Lead screw material: stainless steel
  • Lead screw end machined 6h9x17 mm
  • Stroke 250 mm or 500 mm
Configure drylin SHT linear modules individually!
    • Thread type: Trapezoidal threads
    Upon request
    2 items, thereof ready for shipping:
    2 in 4 weeks
    To the product page

    drylin® SHT-12 linear module with position indicator

    • with plain bearing
    • Lead screw material: stainless steel
    • With position indicator and lead screw clamp
    • Stroke lengths: 250mm or 500mm
    Configure drylin SHT linear modules individually!
    • Thread type: Trapezoidal threads
    Upon request
    2 items, thereof ready for shipping:
    2 in 24 hours
    To the product page

    drylin® SAW-0630 linear module with motor

    • With trapezoidal thread TR8x1.5
    • NEMA17 stepper motor with JST connector
    • Carriage length: 60mm
    • Stroke length: 250 mm
    Configure individual linear module!
    • Thread type: Trapezoidal threads
    582.08 USD/Pc.
    1 items, thereof ready for shipping:
    1 in 24 hours
    To the product page

    drylin® SAW-1040 linear module with stepper motor

    • Trapeziodal lead screw TR10x2
    • NEMA23 stepper motor
    • Carriage length: 69mm
    • Stroke length: 500mm
    Configure individual linear module!
    • Thread type: Trapezoidal threads
    751.95 USD/Pc.
    1 items, thereof ready for shipping:
    1 in 24 hours
    To the product page

    drylin® QLA | Telescopic actuator | Electric; NEMA17, lead screw motor

    Product information
    • Manual or electric adjustment with telescopic guide
    • Drive: NEMA17 lead screw motor with or without encoder
    • Max. extension length: 300mm
    • Max. compressive strength 100N
    Upon request
    4 items, thereof ready for shipping:
    4 in 5 working days
    To the product page

    drylin® QLA | Telescopic actuator | Electric; NEMA17, lead screw motor with encoder

    Product information
    • Manual or electric adjustment with telescopic guide
    • Drive: NEMA17 lead screw motor with or without encoder
    • Max. extension length: 300mm
    • Max. compressive strength 100N
    Upon request
    3 items, thereof ready for shipping:
    3 in 5 working days
    To the product page

    drylin® SLW-1030 linear module with lead screw

    • Compact type
    • Lead screws with ball bearings
    • Carriage length: 48mm
    • Stroke length max. 400mm
    Configure individual linear module!

    drylin® SAW-1660 linear module with lead screw

    • Flat and compact
    • High torsional stability
    • Fully supported
    • Carriage length: 100mm
    • Stroke length max. 750mm
    Configure individual linear module!

    drylin® SAW-0630 linear module with lead screw

    • Flat and compact
    • High torsional stability
    • Fully supported
    • Carriage length: 60mm
    • Stroke length max. 300mm
    Configure individual linear module!
