drylin® E Linear modules with toothed belt

List
Tile

Number of products: 19

drylin® ZLW-0630 basic with stepper motor
drylin® ZLW-0630 basic with stepper motor
  • Toothed belt drive with steel cable
  • Carriage length: 60mm
  • NEMA17 stepper motor with stranded wire
  • Stroke length: 300
→Configure individual linear module!
620.73 USD/Pc.
1 items, thereof ready for shipping:
1 in 24 hours
To the product page

drylin® ZLW-0660S linear axis with toothed belt drive
drylin® ZLW-0660S linear axis with toothed belt drive
  • PU toothed belt with steel cable
  • Carriage length: 100mm
  • Feed rate: 54 mm/rev
  • Installation size: Ø 06
  • Belt tension: 150N
  • Stroke length: 250mm
→Configure individual linear module!
702.38 USD/Pc.
2 items, thereof ready for shipping:
2 in 24 hours
To the product page

drylin® ZLW-1080S linear axis with toothed belt drive
drylin® ZLW-1080S linear axis with toothed belt drive
  • PU toothed belt with steel cable
  • Carriage length: 100mm
  • Installation size: Ø10
  • Belt tension: 200 N
  • Stroke lengths: 500mm or 1000mm
→  Configure individual linear module!
791.78 USD/Pc.
2 items, thereof ready for shipping:
2 in 24 hours
To the product page

drylin® ZLW-1040 basic with stepper motor
drylin® ZLW-1040 basic with stepper motor
  • Toothed belt drive with steel cable
  • Carriage length: 100mm
  • NEMA23 Motor with stranded wire
  • Stroke length: 500
→Configure individual linear module!
774.51 USD/Pc.
1 items, thereof ready for shipping:
1 in 24 hours
To the product page

drylin® ZLW-1080 standard with stepper motor
drylin® ZLW-1080 standard with stepper motor
  • Toothed belt drive with steel cable
  • Carriage length: 100 mm
  • NEMA23XL stepper motor with JST connector
  • Stroke length: 1000mm
→Configure individual linear module!
1,278.90 USD/Pc.
1 items, thereof ready for shipping:
1 in 24 hours
To the product page

drylin® ZLN-40 linear module with toothed belt
drylin® ZLN-40 linear module with toothed belt
  • Flat type with 28mm height
  • Vertical load from 30N
  • Carriage length: 50mm
  • Stroke length max. 750mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-0630B linear module with toothed belt
drylin® ZLW-0630B linear module with toothed belt
  • Cost-effective deflection axis consisting of stainless-steel square section and high-performance polymer
  • Neoprene toothed belts with fibre glass reinforcement
  • Carriage length: 60mm
  • Stroke length max. 1,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-0660B linear module with toothed belt
drylin® ZLW-0660B linear module with toothed belt
  • One-piece stainless steel deflection
  • Effective PU toothed belt with steel cables
  • Carriage length: 100mm
  • Stroke length max. 1,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-1040B linear module with toothed belt
drylin® ZLW-1040B linear module with toothed belt
  • Cost-effective deflection axis consisting of stainless-steel square section and high-performance polymer
  • Neoprene toothed belts with fibre glass reinforcement
  • Carriage length: 100mm
  • Stroke length max. 2,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-1040B linear module with toothed belt
drylin® ZLW-1040B linear module with toothed belt
  • One-piece stainless steel deflection
  • Effective PU toothed belt with steel cables
  • Carriage length: 100mm
  • Stroke length max. 2,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-1080B linear module with toothed belt
drylin® ZLW-1080B linear module with toothed belt
  • One-piece stainless steel deflection
  • Effective PU toothed belt with steel cables
  • Carriage length: 100mm
  • Stroke length max. 2,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-10160B linear module with toothed belt
drylin® ZLW-10160B linear module with toothed belt
  • Variable shaft span of 120/160/200mm
  • Effective deflection axis and toothed belt
  • Also available in stainless steel
  • Carriage length: 150mm
  • Stroke length max. 2,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-10120B linear module with toothed belt
drylin® ZLW-10120B linear module with toothed belt
  • Variable shaft span of 120/160/200mm
  • Effective deflection axis and toothed belt
  • Also available in stainless steel
  • Carriage length: 150mm
  • Stroke length max. 2,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-10200B linear module with toothed belt
drylin® ZLW-10200B linear module with toothed belt
  • Variable shaft span of 120/160/200mm
  • Effective deflection axis and toothed belt
  • Also available in stainless steel
  • Carriage length: 150mm
  • Stroke length max. 2,000mm
→Configure individual linear module!
Upon request
To the product page

drylin® ZLW-1660B linear module with toothed belt
drylin® ZLW-1660B linear module with toothed belt
  • One-piece stainless steel deflection
  • Effective PU toothed belt with steel cables
  • Carriage length: 100mm
  • Stroke length max. 3,000mm
→Configure individual linear module!
Upon request
To the product page
