Energy chains for long travels and heavy duty purposes

Energy chains for heavy-duty applications & long travels

The E4.1 - The energy chain for almost every application. Our energy chains are subjected to the highest loads in our in-house test laboratory to test quality and service life. The E4.1 impresses with its long service life, high stability and modularity. Whether in heavy-duty applications or for travel distances of over 800 metres - reliability is guaranteed. The E4/4HD offers the required stability in the event of heavy soiling or high humidity.

Typical industries and applications: Indoor cranes, composting plants, sewage treatment plants...

E4.1

A series for almost every application

Internal heights: 30 to 800 mm
Crossbar removable in inner and outer radius
For particularly demanding applications
Rear grip for optimum lateral stability
High thrust on long travels and for long unsupported lengths
Noise-damping "brakes" and noise dampers as an option
Outer and inner link for quick assembly
With or without pretension

To the E4.1 shop

E4/4

High additional load for long travel distances

Internal heights: 56 to 80 mm
Full-width: crossbar removable in the inner and outer radius
High stability
For particularly demanding tasks
Ideal for heavy-duty applications

To the E4/4 shop

Friction minimised, service life doubled

Internal heights: 32 to 80 mm
Full web: crossbar removable in inner and outer radius
Longer service life thanks to maintenance-free tribopolymer plain bearings in the connection of the chain links
Long travel distances up to 800 m and more
High filling weight up to 30 kg/m
Speeds up to >5 m/s
Intelligent wear monitoring possible

To the P4.1 shop
