iglidur® K | Versatile and cost-effective for medium temperatures


• Low moisture absorption
• Wear-resistant
• Cost-effective
• Lubrication- and maintenance-free
• Standard range from stock

iglidur® K is the general purpose bearing with flange for medium temperatures, low moisture absorption and good environmental resistance.

Typical application areas

Printing industry
Electronic manufacturing
Plastic machines
Medical technology
Packaging industry

You can find further applications here:
Industry solutions


When to use it? When you need a cost-effective general purpose bearing For use in wet environments When good wear resistance is required at medium loads

When not to use it? When highest wear resistance is necessary iglidur® W300, sleeve bearing with flange, mm If high media resistance is required iglidur® X6, sleeve bearing with flange, mm When a high-temperature bearing is needed iglidur® H, sleeve bearing with flange, mm

Use our filter options to find the suitable product

Tolerances and measurement system
The installation dimensions and tolerances of iglidur® plain bearings are a function of the material and wall thicknesses. For each material, the moisture absorption and the thermal expansion are decisive factors. Plain bearings with low moisture absorption can be designed with a minimal bearing clearance. The rule for wall thickness: the thicker the wall of the bearings, the larger the clearances must be.
Testing methods

Assembly
iglidur® plain bearings are press-fit bearings. The inner diameter adjusts only after press-fitting in the correctly toleranced housing. The press-fit excess dimension can be up to 2% of the inner diameter. This ensures the secure press-fitting of the bearing. Axial or radial movement in the housing are prevented this way.
iglidur® - assembling, gluing, machining
